Carboxymethyl Cellulose (CMC)
|
|
Index |
HV-CMC |
LV-CMC |
Apparent viscosity |
in distilled water |
30 cps min |
90cps max |
in 4% salt water |
30cps min |
iturated watern sa |
30cps min |
| Filtration loss(cm3) |
10 max |
10 max |
| Application |
:Oil drilling grade CMC used in fracturing fluid ,drilling fluid and well cementing fluid as fluid loss controller and tackifier. It can protect the shaft wall and prevent mud loss thus enhance recovery efficiency.
GB/T5005-2001 |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
CMC - Textile, Dyeing grade |
|
| |
| Index |
Technique Requirements |
| IH7 |
IM7 |
IM6 |
IM5 |
IM4 |
| Viscosity(2% aqueous solution, mpas) |
800-1200 |
600-800 |
300-600 |
200-500 |
100-300 |
| Degree of Substitute |
0.70 min |
0.70 min |
0.70 min |
0.50 min |
0.50 min |
| Purity (%) |
90 min |
75 min |
70 min |
60 min |
60 min |
| PH value |
6.0-8.5 |
6.0-8.5 |
6.0-8.5 |
8-10 |
8-10 |
| Loss on Drying(%) |
10 max |
10 max |
10 max |
25 max |
10 max |
| Applications: CMC used in textile and dyeing industry as sizing agent and dying adjuvant to make stock limpidity and transparence. It is easy a good stabilizer of the stock and helps to form film. It is easy to desizing. |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
CMC - Papermaking grade |
|
| |
|
Technique Requirements |
ZZH-1 |
ZZH-2 |
ZZH-3 |
ZZH-4 |
ZZH-5 |
Viscosity(mpas) |
2% |
20max |
20-50 |
50-150 |
300-800 |
800-1200 |
4% |
50max |
50-150 |
|
|
|
Degree of Substitute |
0.70-0.95 |
0.70-0.90 |
0.60-0.80 |
0.60-0.80 |
0.65-0.85 |
Purity (%) |
95 min |
90min |
80 min |
85min |
90min |
PH value |
6.0-8.5 |
| Loss on Drying (%) |
10 max |
| Applications |
In paper industry, CMC used for paper coating. It is useful for the dispersing and flowing of the pigments, enhancing the finish and smoothness of the printing quality. It is used for surface sizing to strengthen the paper and reduce the printing dusts. It can increase moisture and improve retention rate in pulping. |
|
|
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
CMC - Toothpaste Grade |
|
| |
| Type |
Technique Requirements |
| D.S |
Viscosity(2% aqueous solution,mpas) |
PH value |
Moisture(%,max) |
NaCI |
Heavy Metal(%,pb) |
Arsenic(%) |
Iron(%) |
| IH10 |
1.00
min |
900-1200 |
6.5-8.0 |
8.0 |
3.0max |
0.002max |
0.0005max |
0.03max |
| IH9 |
0.90
min |
900-1200 |
6.5-8.0 |
8.0 |
3.0max |
0.002max |
0.0005max |
0.03max |
Applications: There are many kinds of thickener for toothpaste use in chemical industry, but the application of CMC is most extensive. CMC acts as colloid that helps to shape and conglutinate the dense-degree suit and can keep the stable cream body appearance. After CMC fuse deeply the light rate is high, have better flow to change the function and touch to change the function. |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
CMC - Detergent grade |
|
| |
|
Technique Requirement |
XYF-1 |
XYF-2 |
XYF-3 |
XD-1 |
XD-2 |
Moisture (%) |
10 |
10 |
10 |
10 |
10 |
Purity (%) |
55 |
60 |
70 |
70 |
90 |
Degree of Substitute |
0.5-0.7 |
0.5-0.7 |
0.5-0.7 |
¡Ư0.60 |
¡Ư0.70 |
Viscosity(cps) |
5-40 |
5-40 |
5-40 |
300-800 |
£¾800 min |
1% aqueous solution |
2% aqueous solution |
PH Value |
8-11.5 |
8-11.5 |
8-11.5 |
7-10 |
6.5-8.5 |
Applications: Detergent grade CMC, when used in liquid, paste detergent, acts as stabilizing agent and thickening agent; when used in detergent powder, CMC can effectively prevent washes from becoming contaminated after being washed by synthetic detergent. |
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
CMC - Food Grade |
|
| |
Type |
FVHX |
FHX |
FMX |
FLX |
Viscosity scope(mpas) |
500 min |
200-500 |
400-2000 |
25-400 |
1% aqueous solution |
2% aqueous solution |
Technique Requirements |
Viscosity(2% aqueous solution, mpas) |
25 min |
Degree of Substitute |
0.2-1.5 |
PH Value (10g/l aqueous solution) |
6.0-8.5 |
Loss on Drying (%) |
10.0 max |
Chloride (cl, %) |
1.2 max |
Arsenic (As, %) |
0.0002 max |
Lead (Pb, %) |
0.0005 max |
Heavy Metal (Pb, %) |
0.0015 max |
Iron (Fe, %) |
0.02 max |
Our company can produce food grade CMC with high purity, very high viscosity according to the customer¡¯s requirements. Purity: 99% min Viscosity(1% aqueous solution, Brookfield): FVH6: 5000 min mpa.s; FHV9: 2000 min mpa.s
Applications: Food grade CMC is widely used in Food Industry as thickener, stabilizer, moisture sustainer and emulsifier to improve taste. It is used in making yoghurt, beverage, jelly, syrup, cookies, instant noodles and inebriant. |
|
|
|
|
|
|
| |
|
|
| |
|
|
| |
|
|
| |
